实验室里观察薄层板的紫外灯,紫外诱导实验用紫外线灯
LE系列双波长手持式紫外线灯(LEAC-280L、LEAC-260L)的特点:
1.采用进口铝反射镜。
2.紫外线灯管有4w、6w、8w等多种功率可供选择。
3.长波紫外线灯管可选择自滤色紫外线灯管和标准紫外线灯管。
4.采用的滤色片保证的紫外线强度及寿命。
5.铝合金氧化外壳。
6.可选择单灯管或双灯管模式。
8.供电方式选择:24v交流适配器,内置24v锂电池组供电。
LE系列双波长手持式紫外线灯(LEAC-280L、LEAC-260L)的产品说明:
LEAB-260 | 长波+中波 | 1只6w 365nm紫外线灯管,1只6w 312nm紫外线灯管,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEAC-260 | 长波+短波 | 1只6w 365nm紫外线灯管,1只6w 254nm紫外线灯管,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEBC-260 | 中波+短波 | 1只6w 254nm紫外线灯管,1只6w 312nm紫外线灯管,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEAB-260L | 长波+中波 | 1只6w 365nm紫外线灯管,1只6w 312nm紫外线灯管,带有滤色片,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEAC-260L | 长波+短波 | 1只6w 365nm紫外线灯管,1只6w 254nm紫外线灯管,带有滤色片,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEBC-260L | 中波+短波 | 1只6w 254nm紫外线灯管,1只6w 312nm紫外线灯管,带有滤色片,外形尺寸: 26.0长x8.3宽x6.4cm高。 |
LEAB-280 | 长波+中波 | 1只8w 365nm紫外线灯管,1只8w 312nm紫外线灯管,外形尺寸: 33.7长x8.3宽x6.4cm高。 |
LEAC-280 | 长波+短波 | 1只8w 365nm紫外线灯管,1只8w 254nm紫外线灯管,外形尺寸: 33.7长x8.3宽x6.4cm高。 |
LEBC-280 | 中波+短波 | 1只8w 254nm紫外线灯管,1只8w 312nm紫外线灯管,外形尺寸: 33.7长x8.3宽x6.4cm高。 |
LEAB-280L | 长波+中波 | 1只8w 365nm紫外线灯管,1只8w 312nm紫外线灯管,带有滤色片,外形尺寸: 33.7长x8.3宽x6.4cm高。 |
LEAC-280L | 长波+短波 | 1只8w 365nm紫外线灯管,1只8w 254nm紫外线灯管,带有滤色片,外形尺寸:33.7长x8.3宽x6.4cm高。 |
LEBC-280L | 中波+短波 | 1只8w 254nm紫外线灯管,1只8w 312nm紫外线灯管,带有滤色片,外形尺寸: 33.7长x8.3宽x6.4cm高。 |
Applications for the three wave lengths include...
LOCATE PET URINE SOURCES...
The amber-colored pet urine is composed of protein metabolism waste products, with feline diets typically protein richer than dogs. The urine will glow in the dark using a blacklight (longwave UV light). Since the UV light is relatively weak, it works best to darken the room as much as possible.
Using lower wattage blacklights (4 watt) require being close to the inspection area with it as dark as possible.
RODENT CONTROL...
Detect rodent presence and contamination in warehouses, storerooms, etc. by using an ultraviolet lamp to search out and fluoresce rodent urine. Dry rodent urine glows a blue-white if fresh to a yellow-white if old when exposed to longwave ultraviolet light. Rodent hair glows blue-white and is easily identified on sacks or intermixed with food grains.
FORGERY ANALYSIS...
Forgeries of bank notes, standard checks and travellers' checks are mainly printed on inferior bleached paper or photocopied. Forgeries will glow under UV light and bona fides will be completely dull. Many newer credit cards have an invisible imprint on the front. American Express uses "AMEX". If no imprint, the card is a forgery. Alterations of legal documents such as careful erasure or ink eradication and altering paper textures are detectable with UV light.
CURRENCY VERIFICATION...
Authentic U.S. paper currency has embedded stripes which will fluoresce under ultraviolet light as follows: $5 glows blue, $10 glows orange, $20 glows green, $50 glows yellow, and $100 glows red. The $1.00 bill has no stripe.
GEMSTONE and MINERAL INSPECTION...
UV Light can react with the chemicals of a mineral specimen and cause it to glow, called fluorescence. Color and intensity of the fluorescence can identifty many materials. Some minerals and gemstones will fluoresce under shortwave UV ligh and not fluoresce under longwave.
ARSON DETECTION...
In arson detection, accelerants' fluorescent glow is greater when exposed longer to heat. Their evidence is not always visible as they are absorbed by the fire but UV light can expose them.
Volatile hydrocarbons such as gasoline, grease, paints and others fluoresce when exposed to UV, and can be seen as fragments of incendiary devices. Ambient light must be minimized for use of UV light at a fire scene.
CRIME SCENE INSPECTION...
Illegal dumping can be tracked at night using UV light.
UV light is used to detect the presence of trace evidence in forensic investigations. Blood, urine, semen and saliva can present visible fluorescence.
ARTWORK INSPECTION ...
UV or black light reveals changes on the surface of objects as it causes specific fluorescence in materials depending on composition and age. UV fluorescence can show overpainting or retouching and identify types of stains.
One can detect repair in paintings and rugs using UV light, as differences can be seen between the chemical composition of newer inks, paints, and dyes and that of the originals.
RESEARCH ...
Gel Electrophoresis results can be analyzed quantitatively by visualizing the gel with UV light and a gel imaging device.
INDUSTRIAL ...
UV Light curing adhesives can cure in as little as a second in many industrial markets such as electronics, telecommunications, medical, aerospace, glass, and optical.
MEDICAL ...
In dermatology, UV radiation is known to suppress the immune system and reduce inflammatory responses.
